Product DetailSpecification/DimensionsĐặc điểm kỹ thuật / Kích thướcĐặc điểm kỹ thuật / Kích thước
-
Inner Dia. d(Ø)
-
Outer Dia. D(Ø)
-
Overall Length L(mm)
-
type
- MPBZ
-
CADCAD
- 2D
- 3D
Days to ShipSố ngày giao hàng
-
- Alltất cả các
- Same day
- 4 Day(s) or Less
- 6 Day(s) or Less
- 11 Day(s) or Less
Specify AlterationsChỉ định thay đổi
Oil Free Bushings - Copper Alloy Straight, Standard
- Volume Discount
- All
- Sale Items
Copy Part Number URL to Clipboard
The part number URL has been copied into your clipboard.
-
- From :
- 78,230VND/Unit
-
- Order Qty :
-
-
- Total Price :
- ---
-
- Days to ship :
- ---
Select part number to Order Now/ Add to Cart
Similar Products
Product DetailProduct Description
- Oil Free Bushings - Copper Alloy Straight, Standard type, MPBZ series from MISUMI.
- Copper Alloy Bushings in general use. Straight Shape Type.
- Recommended mating shaft for I.D. of Copper oil-free bushing MPBZ series are d8: General use (High Load), e7: General use (Light Load), f8: High precision use, g6: High precision use (Intermittent operation).
- Use of rotation stopper screws is recommended to affix bushings.
- The Copper oil-free bushing MPBZ series is made of High tensile brass alloy with solid lubricant embedded.
Part Number
- Incomplete part number.
Please use left hand selections to complete a part number.Incomplete part number.
Please use left hand selections to complete a part number.
| Part Number | Price | Minimum Order Qty. | Volume Discount | Days to ShipSố ngày giao hàng | RoHS | Inner Dia. d (Ø) | Outer Dia. D (Ø) | Overall Length L (mm) |
|---|---|---|---|---|---|---|---|---|
102,384 VND 51,192 VND | 1 Piece(s) | Available | Same day | 10 | 5 | 9 | 8 | |
102,384 VND | 1 Piece(s) | Available | 4 Day(s) or more | 10 | 5 | 9 | 9 | |
102,384 VND | 1 Piece(s) | Available | Same day | 10 | 5 | 9 | 10 | |
102,384 VND 56,311 VND | 1 Piece(s) | Available | Same day | 10 | 5 | 9 | 12 | |
120,525 VND | 1 Piece(s) | Available | Same day | 10 | 5 | 9 | 15 | |
91,124 VND | 1 Piece(s) | Available | Same day | 10 | 6 | 10 | 8 | |
91,124 VND | 1 Piece(s) | Available | 4 Day(s) or more | 10 | 6 | 10 | 9 | |
91,124 VND | 1 Piece(s) | Available | Same day | 10 | 6 | 10 | 10 | |
91,124 VND | 1 Piece(s) | Available | 4 Day(s) or more | 10 | 6 | 10 | 12 | |
102,384 VND 61,430 VND | 1 Piece(s) | Available | Same day | 10 | 6 | 10 | 15 | |
111,351 VND | 1 Piece(s) | Available | 6 Day(s) or more | 10 | 6 | 10 | 16 | |
120,525 VND | 1 Piece(s) | Available | 4 Day(s) or more | 10 | 6 | 10 | 19 | |
120,525 VND | 1 Piece(s) | Available | 4 Day(s) or more | 10 | 6 | 10 | 20 | |
81,949 VND | 1 Piece(s) | Available | Same day | 10 | 8 | 12 | 8 | |
81,949 VND | 1 Piece(s) | Available | 4 Day(s) or more | 10 | 8 | 12 | 9 | |
81,949 VND | 1 Piece(s) | Available | Same day | 10 | 8 | 12 | 10 | |
81,949 VND | 1 Piece(s) | Available | Same day | 10 | 8 | 12 | 12 | |
91,124 VND | 1 Piece(s) | Available | Same day | 10 | 8 | 12 | 15 | |
104,678 VND | 1 Piece(s) | Available | 6 Day(s) or more | 10 | 8 | 12 | 16 | |
106,972 VND | 1 Piece(s) | Available | 4 Day(s) or more | 10 | 8 | 12 | 19 | |
106,972 VND | 1 Piece(s) | Available | Same day | 10 | 8 | 12 | 20 | |
129,701 VND | 1 Piece(s) | Available | 6 Day(s) or more | 10 | 8 | 12 | 25 | |
81,949 VND | 1 Piece(s) | Available | Same day | 10 | 10 | 14 | 8 | |
81,949 VND | 1 Piece(s) | Available | 4 Day(s) or more | 10 | 10 | 14 | 9 | |
81,949 VND | 1 Piece(s) | Available | Same day | 10 | 10 | 14 | 10 | |
81,949 VND | 1 Piece(s) | Available | 6 Day(s) or more | 10 | 10 | 14 | 12 | |
91,124 VND | 1 Piece(s) | Available | Same day | 10 | 10 | 14 | 15 | |
91,124 VND | 1 Piece(s) | Available | Same day | 10 | 10 | 14 | 16 | |
91,124 VND | 1 Piece(s) | Available | 4 Day(s) or more | 10 | 10 | 14 | 19 | |
91,124 VND | 1 Piece(s) | Available | 4 Day(s) or more | 10 | 10 | 14 | 20 | |
115,939 VND | 1 Piece(s) | Available | Same day | 10 | 10 | 14 | 25 | |
134,288 VND | 1 Piece(s) | Available | Same day | 10 | 10 | 14 | 30 | |
81,949 VND | 1 Piece(s) | Available | 4 Day(s) or more | 10 | 12 | 18 | 8 | |
91,124 VND | 1 Piece(s) | Available | 4 Day(s) or more | 10 | 12 | 18 | 9 | |
91,124 VND | 1 Piece(s) | Available | 4 Day(s) or more | 10 | 12 | 18 | 10 | |
91,124 VND | 1 Piece(s) | Available | 4 Day(s) or more | 10 | 12 | 18 | 12 | |
100,091 VND | 1 Piece(s) | Available | Same day | 10 | 12 | 18 | 15 | |
81,020 VND | 1 Piece(s) | 6 Day(s) or more | 10 | 12 | 18 | 16 | ||
100,091 VND | 1 Piece(s) | Available | 4 Day(s) or more | 10 | 12 | 18 | 19 | |
100,091 VND | 1 Piece(s) | Available | 11 Day(s) | 10 | 12 | 18 | 20 | |
115,939 VND | 1 Piece(s) | Available | 4 Day(s) or more | 10 | 12 | 18 | 25 | |
125,113 VND | 1 Piece(s) | Available | Same day | 10 | 12 | 18 | 30 | |
150,136 VND | 1 Piece(s) | Available | 4 Day(s) or more | 10 | 12 | 18 | 35 | |
106,972 VND | 1 Piece(s) | Available | 4 Day(s) or more | 10 | 13 | 19 | 9 | |
80,640 VND | 1 Piece(s) | Same day | 10 | 13 | 19 | 10 | ||
125,113 VND | 1 Piece(s) | Available | 4 Day(s) or more | 10 | 13 | 19 | 12 | |
125,113 VND | 1 Piece(s) | Available | 4 Day(s) or more | 10 | 13 | 19 | 15 | |
129,701 VND | 1 Piece(s) | Available | 4 Day(s) or more | 10 | 13 | 19 | 16 | |
134,288 VND | 1 Piece(s) | Available | 4 Day(s) or more | 10 | 13 | 19 | 19 | |
107,550 VND | 1 Piece(s) | Same day | 10 | 13 | 19 | 20 | ||
102,710 VND | 1 Piece(s) | Same day | 10 | 13 | 19 | 25 | ||
154,723 VND | 1 Piece(s) | Available | 4 Day(s) or more | 10 | 13 | 19 | 30 | |
172,865 VND | 1 Piece(s) | Available | 4 Day(s) or more | 10 | 13 | 19 | 35 | |
258,940 VND | 1 Piece(s) | Same day | 10 | 15 | 21 | 9 | ||
94,460 VND | 1 Piece(s) | Same day | 10 | 15 | 21 | 10 | ||
125,113 VND | 1 Piece(s) | Available | 4 Day(s) or more | 10 | 15 | 21 | 12 | |
125,113 VND | 1 Piece(s) | Available | Same day | 10 | 15 | 21 | 15 | |
129,701 VND | 1 Piece(s) | Available | 4 Day(s) or more | 10 | 15 | 21 | 16 | |
134,288 VND | 1 Piece(s) | Available | 4 Day(s) or more | 10 | 15 | 21 | 19 | |
134,288 VND | 1 Piece(s) | Available | Same day | 10 | 15 | 21 | 20 |
Loading...Tải…
Basic InformationThông tin cơ bản
| Type | Straight | Metal Type | High-Tensile Brass Alloy | Max. Allowable PV Value Range(N/mm2•m/s) | 1.1~2.0 |
|---|---|---|---|---|---|
| Max. Allowable PV Value(N/mm2•m/s) | 1.65 | Max. Allowable Surface Pressure P(N/mm2) | 29 | Maximum Allowable Velocity(m/s) | 0.5 |
| Mounting Hole Fits | H7 | Operating Temperature Range(°C) | -40::150 |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer toCác thông số kỹ thuật và kích thước của mã sản phẩm có thể không được bao phủ đầy đủ. Để biết chi tiết chính xác, hãy tham khảo manufacturer catalogsdanh mục nhà sản xuất ..
