Product DetailSpecification/DimensionsĐặc điểm kỹ thuật / Kích thướcĐặc điểm kỹ thuật / Kích thước
-
Material
- Stainless Steel
- Stainless Steel
-
Nominal of Thread Rc (PT) or T or T1 or Q or Q1
- 1/8B(6A)
- 1/4B(8A)
- 3/8B(10A)
- 1/2B(15A)
- 3/4B(20A)
-
Nominal of Thread T2 or Q2
- 1/4B(8A)
- 3/8B(10A)
- 1/2B(15A)
- 3/4B(20A)
- 1B(25A)
-
type
- STUNPS
- STUNPSS
-
CADCAD
- 2D
- 3D
Days to ShipSố ngày giao hàng
-
- Alltất cả các
- Same day
- 4 Day(s) or Less
- 6 Day(s) or Less
Specify AlterationsChỉ định thay đổi
Low Pressure Fittings/Reducer Nipple
- Volume Discount
- All
- Sale Items
Copy Part Number URL to Clipboard
The part number URL has been copied into your clipboard.
-
- From :
- 61,900VND/Unit
-
- Order Qty :
-
-
- Total Price :
- ---
-
- Days to ship :
- ---
Select part number to Order Now/ Add to Cart
Similar Products
Product DetailProduct Description
[Connection Type]Thread to thread, reducing; Material: SCS13A/SCS14A
Part Number
- Incomplete part number.
Please use left hand selections to complete a part number.Incomplete part number.
Please use left hand selections to complete a part number.
| Part Number |
|---|
| STUNPS12 |
| STUNPS13 |
| STUNPS23 |
| STUNPS24 |
| STUNPS34 |
| STUNPS36 |
| STUNPS46 |
| STUNPS48 |
| STUNPS68 |
| STUNPSS12 |
| STUNPSS13 |
| STUNPSS23 |
| STUNPSS24 |
| STUNPSS34 |
| STUNPSS36 |
| STUNPSS46 |
| STUNPSS48 |
| STUNPSS68 |
| Part Number | Price | Minimum Order Qty. | Volume Discount | Days to ShipSố ngày giao hàng | RoHS | Material | Nominal of Thread Rc (PT) or T or T1 or Q or Q1 | Nominal of Thread T2 or Q2 |
|---|---|---|---|---|---|---|---|---|
90,290 VND | 1 Piece(s) | Available | Same day | 10 | [Stainless Steel] SCS13A | 1/8B(6A) | 1/4B(8A) | |
90,290 VND 88,484 VND | 1 Piece(s) | Available | Same day | 10 | [Stainless Steel] SCS13A | 1/8B(6A) | 3/8B(10A) | |
90,290 VND | 1 Piece(s) | Available | Same day | 10 | [Stainless Steel] SCS13A | 1/4B(8A) | 3/8B(10A) | |
61,900 VND | 1 Piece(s) | 4 Day(s) or more | 10 | [Stainless Steel] SCS13A | 1/4B(8A) | 1/2B(15A) | ||
133,871 VND 81,661 VND | 1 Piece(s) | Available | Same day | 10 | [Stainless Steel] SCS13A | 3/8B(10A) | 1/2B(15A) | |
173,908 VND | 1 Piece(s) | Available | Same day | 10 | [Stainless Steel] SCS13A | 3/8B(10A) | 3/4B(20A) | |
173,908 VND | 1 Piece(s) | Available | Same day | 10 | [Stainless Steel] SCS13A | 1/2B(15A) | 3/4B(20A) | |
224,161 VND | 1 Piece(s) | Available | Same day | 10 | [Stainless Steel] SCS13A | 1/2B(15A) | 1B(25A) | |
224,161 VND | 1 Piece(s) | Available | Same day | 10 | [Stainless Steel] SCS13A | 3/4B(20A) | 1B(25A) | |
177,244 VND | 1 Piece(s) | Available | 6 Day(s) or more | 10 | [Stainless Steel] SCS14A | 1/8B(6A) | 1/4B(8A) | |
177,244 VND | 1 Piece(s) | Available | 6 Day(s) or more | 10 | [Stainless Steel] SCS14A | 1/8B(6A) | 3/8B(10A) | |
177,244 VND | 1 Piece(s) | Available | 6 Day(s) or more | 10 | [Stainless Steel] SCS14A | 1/4B(8A) | 3/8B(10A) | |
230,834 VND | 1 Piece(s) | Available | 6 Day(s) or more | 10 | [Stainless Steel] SCS14A | 1/4B(8A) | 1/2B(15A) | |
230,834 VND | 1 Piece(s) | Available | 6 Day(s) or more | 10 | [Stainless Steel] SCS14A | 3/8B(10A) | 1/2B(15A) | |
304,443 VND | 1 Piece(s) | Available | 6 Day(s) or more | 10 | [Stainless Steel] SCS14A | 3/8B(10A) | 3/4B(20A) | |
304,443 VND | 1 Piece(s) | Available | 6 Day(s) or more | 10 | [Stainless Steel] SCS14A | 1/2B(15A) | 3/4B(20A) | |
388,061 VND | 1 Piece(s) | Available | 6 Day(s) or more | 10 | [Stainless Steel] SCS14A | 1/2B(15A) | 1B(25A) | |
539,160 VND | 1 Piece(s) | 6 Day(s) or more | 10 | [Stainless Steel] SCS14A | 3/4B(20A) | 1B(25A) |
Loading...Tải…
Basic InformationThông tin cơ bản
| Connecting Shape | Hex Nipples | Connection Type | Thread <-> Thread, Unequal Dia. | Connecting Thread Type (1) | R (PT Male Threaded) |
|---|---|---|---|---|---|
| Connecting Thread Type (2) | R (PT Male Threaded) | Type | Fitting | Max. Operating Pressure(MPa) | 2 |
| Surface Treatment | No |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer toCác thông số kỹ thuật và kích thước của mã sản phẩm có thể không được bao phủ đầy đủ. Để biết chi tiết chính xác, hãy tham khảo manufacturer catalogsdanh mục nhà sản xuất ..
